Fortinet FortiManager 410G
Automation-Driven Centralized Device Management from a Single Console

Highlights:

Single Pane Management

• Device Configuration and Provisioning
• Security Policy and Objects Management
• FortiManager High Availability (HA)
• Secure SD-WAN
• Multi-Tenancy and Role-Based Administration

Security Fabric Automation

• Network and Security Operations Visibility (NOC/SOC)
• Automation and Connectors
• Expanded Operations Capabilities
• Security Fabric and Third Party Integration

Monitoring and Visibility

• Manage and Monitor with Deep Visibility

NOC Cloud Services

• Management Extensions
• Dynamic Cloud Security
• Trusted Platform Module (TPM) Encryption

FortiManager Virtual Machines

FortiManager Virtual Machines are a virtual version of the hardware appliance and are designed to run on many virtualization platforms, offering all the latest features of the FortiManager appliance. They allow organizations to centrally manage any number of Fortinet Network Security Fabric devices and scale from several to thousands, supporting centralized management, best practices compliance, and automated workflows to deliver superior protection against threats. FortiManager VMs are available in both a subscription and perpetual offering.

• FortiManager VM-S
• FortiManager VM

Specifications:

	FortiManager 200G	FortiManager 410G
Capacity and Performance
Devices/VDOMs (Default)1	30	150
Devices/VDOMs (Maximum)3	-	-
Sustained Log Rates	50	50
GB/Day	2	2
Hardware Specifications
Storage Capacity	8 TB (2 x 4 TB)	32 TB (8 x 4 TB)
Usable Storage (After RAID)	4 TB	24 TB
RAID Levels Supported	RAID 0/1	RAID 0/1,1s/5,5s/6,6s/10/50/60
Default RAID	1	50
Hardware Form Factor	1 RU Rackmount	2 RU Rackmount
Total Interfaces	4xRJ45 GE	4 x GE RJ45, 2 x SFP
Console Port	RJ45	RJ45
Removable Hard Drives	No
Redundant Hot Swap Power Supplies
TPM Encryption	Gen2
Dimensions
Height x Width x Length (inches)	1.73 x 17.24 x 16.38	3.5 x 17.5 x 22.2
Weight	22.5 lbs (10.2 kg)	35.27 lbs (16 kg)
Environment
AC Power Supply	100–240V AC, 50-60 Hz	100–240V AC, 50-60 Hz
Power Consumption (Average / Maximum)	90.1W / 99 W	140 W / 182 W
Heat Dissipation	337.8 BTU/h	621 BTU/h
Operating Temperature	32 - 104° F (0 - 40° C)	32 - 104° F (0 - 40° C)
Storage Temperature	-13–167ºF (-25–75ºC)	-4°–167°F (-20°–75°C)
Humidity	20 to 90% non-condensing	5 to 95% non-condensing
Forced Airflow	Front to Back	Front to Back
Operating Altitude	Up to 7,400 ft (2,250 m)	Up to 7,400 ft (2,250 m)
Compliance
Safety Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

¹ Each Virtual Domain (VDOM) operating on a physical or virtual device counts as one (1) licensed network device
* FGT 7000 Series is supported on all FMG models and does not require Chassis Management.

³ Devices/VDOMs maximum with device add-on license, if supported

Documentation:

Download the Fortinet FortiManager Series Datasheet (PDF).
